RESTful API Development Basics with Express, and MySQL

1. Objectives#

This article will guide you through designing and developing a RESTful API for managing Users, Products, Orders resources, and Nested Resources to display all orders of users and all products in orders, using Node.js and Express to connect directly to a MySQL database with mysql2, and testing with Postman.

2. Install Programs and Setup Database#

Install Node.js LTS Version Download Node.js LTS (Long Term Support) version from https://nodejs.org ↗ and select the recommended LTS version for development.

Setup:
- Download the installer file appropriate for your operating system (Windows, macOS, or Linux)
- Install by double-clicking the installer file and follow the installation steps
- After installation is complete, open Command Prompt or Terminal and check the installation with these commands:
```
node --version
npm --version
```
  bash
- If installed successfully, it will display the versions of Node.js and npm
Install XAMPP (MySQL + phpMyAdmin) Download and install XAMPP from https://www.apachefriends.org ↗ and select the version appropriate for your operating system.

Setup:
- When installation is complete, open XAMPP Control Panel and set Apache and MySQL as Service as shown (requires Administrator privileges)
- Start the Apache and MySQL services to enable the web server and database
- Open a web browser and go to http://localhost/phpmyadmin ↗
- Click on the Databases tab
- In the Create database section, name the database express_mysql_db and click Create
Install Postman Download Postman at https://www.postman.com/downloads/ ↗ Install and open Postman. You will use Postman to test API endpoints (GET, POST, PUT, DELETE).

3. Setup Project and Install MySQL Driver#

Create Node.js Project Open Terminal or Command Prompt and run these commands:

mkdir api-mysql
cd api-mysql
npm init -y
npm install express cors body-parser mysql2
code . # Open VS Code in the project folder (if installed)

bash

Create .env File Create a .env file in the project root to store database connection values:
```
DB_HOST=localhost
DB_USER=root
DB_PASSWORD=
DB_NAME=express_mysql_db
DB_PORT=3306
```
plaintext
- DB_HOST: MySQL Host (localhost)
- DB_USER: Database username (root for XAMPP)
- DB_PASSWORD: Password (leave empty for XAMPP if not set)
- DB_NAME: Database name
- DB_PORT: MySQL Port (3306)

4. Create Database Tables#

Open phpMyAdmin at http://localhost/phpmyadmin ↗ and go to the express_mysql_db database, then click the SQL tab and paste the following SQL commands to create tables:

-- Create Users table
CREATE TABLE users (
  id INT AUTO_INCREMENT PRIMARY KEY,
  fname VARCHAR(100) NOT NULL,
  lname VARCHAR(100) NOT NULL,
  username VARCHAR(50) NOT NULL UNIQUE,
  email VARCHAR(100) NOT NULL UNIQUE,
  avatar VARCHAR(255) NULL
);

-- Create Products table
CREATE TABLE products (
  id INT AUTO_INCREMENT PRIMARY KEY,
  name VARCHAR(200) NOT NULL,
  price INT NOT NULL
);

-- Create Orders table
CREATE TABLE orders (
  id INT AUTO_INCREMENT PRIMARY KEY,
  user_id INT NOT NULL,
  created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
  FOREIGN KEY (user_id) REFERENCES users(id) ON DELETE CASCADE
);

-- Create Order_Product table (join table between Orders and Products)
CREATE TABLE order_product (
  id INT AUTO_INCREMENT PRIMARY KEY,
  order_id INT NOT NULL,
  product_id INT NOT NULL,
  FOREIGN KEY (order_id) REFERENCES orders(id) ON DELETE CASCADE,
  FOREIGN KEY (product_id) REFERENCES products(id) ON DELETE CASCADE
);

sql

Table Structure Summary#

Table	Relationship	Type
users	has many orders	One-to-Many
orders	belongs to one user	Many-to-One
orders	has many products	Many-to-Many
products	appears in many orders	Many-to-Many
order_product	joins orders and products	Join table

View the results in the express_mysql_db database Result from creating tables

SQL Commands Explanation for Creating Tables#

CREATE TABLE - Command to create a new table:

CREATE TABLE table_name (
  column_name data_type constraints
);

sql

Commonly Used Data Types:

INT - Integer numbers
VARCHAR(n) - Character text with maximum length of n characters
TIMESTAMP - Date and time data
TEXT - Unlimited length character text

Commonly Used Constraints:

PRIMARY KEY - Primary key, used to identify each row uniquely
AUTO_INCREMENT - Auto-incrementing number (1, 2, 3, …)
NOT NULL - Data must not be empty
UNIQUE - Data must not be duplicated
DEFAULT - Default value when data is not specified

Table Relationships (Foreign Key):

FOREIGN KEY (column_name) REFERENCES other_table(id)
ON DELETE CASCADE   -- Delete related data when main data is deleted

sql

Example:

-- users table stores user data
id INT AUTO_INCREMENT PRIMARY KEY  -- User ID (auto-increment)
username VARCHAR(50) NOT NULL UNIQUE  -- Username (unique)

-- orders table stores orders
user_id INT NOT NULL
FOREIGN KEY (user_id) REFERENCES users(id) ON DELETE CASCADE
-- user_id links to id in the users table
-- When a user is deleted, their orders will be deleted too

sql

5. Add Sample Data (Seed Data)#

After creating the tables, we need sample data to test the API immediately. Open phpMyAdmin and go to the express_mysql_db database, then click the SQL tab and paste the following SQL commands:

-- Add Users data
INSERT INTO users (id, fname, lname, username, email, avatar) VALUES
(1, 'Karn', 'Yong', 'karn.yong', 'karn.yong@melivecode.com', 'https://www.melivecode.com/users/1.png'),
(2, 'Parkpoom', 'Chaisiriprasert', 'parkpoom', 'parkpoom@melivecode.com', 'https://www.melivecode.com/users/2.png');

-- Add Products data
INSERT INTO products (id, name, price) VALUES
(1, 'Laptop', 39999),
(2, 'Smartphone', 19999),
(3, 'Monitor', 7999);

-- Add Orders data
INSERT INTO orders (id, user_id) VALUES
(1, 1),
(2, 2),
(3, 1);

-- Add Order_Product data (links orders with products)
INSERT INTO order_product (order_id, product_id) VALUES
-- Order #1 (Karn) has Laptop and Smartphone
(1, 1),
(1, 2),
-- Order #2 (Parkpoom) has Smartphone
(2, 2),
-- Order #3 (Karn) has Smartphone and Monitor
(3, 2),
(3, 3);

sql

SQL Commands Explanation for Adding Data#

INSERT INTO - Command to add new data:

INSERT INTO table_name (column1, column2) VALUES (value1, value2);

sql

Add multiple rows at once:

INSERT INTO users (fname, lname, email) VALUES
('Karn', 'Yong', 'karn@example.com'),
('Parkpoom', 'Chaisiriprasert', 'parkpoom@example.com');

sql

Sample Data Added:

Table	Data Added
Users	2 users: Karn and Parkpoom
Products	3 products: Laptop, Smartphone, Monitor
Orders	3 orders
Order_Product	Links orders with products

Sample Data Relationships:

Karn (id: 1) placed 2 orders:
- Order #1: Laptop + Smartphone = 59,998 Baht
- Order #3: Smartphone + Monitor = 27,998 Baht
Parkpoom (id: 2) placed 1 order:
- Order #2: Smartphone = 19,999 Baht

6. Create Database Connection File#

Create a src/db.js file to create a connection pool for connecting to the MySQL database:

// src/db.js
const mysql = require('mysql2/promise');

// Create connection pool
const pool = mysql.createPool({
  host: process.env.DB_HOST || 'localhost',
  user: process.env.DB_USER || 'root',
  password: process.env.DB_PASSWORD || '',
  database: process.env.DB_NAME || 'express_mysql_db',
  port: process.env.DB_PORT || 3306,
  waitForConnections: true,
  connectionLimit: 10,
  queueLimit: 0
});

module.exports = pool;

javascript

Connection Pool Explanation#

Connection Pool is storing database connections for reuse, so you don’t need to open-close a new connection every time.

7. Basic SQL Commands Used in RESTful API#

SELECT - Retrieve Data#

Retrieve all data:

SELECT * FROM users;

sql

Retrieve data by condition:

SELECT * FROM users WHERE id = 1;

sql

Retrieve specific columns:

SELECT fname, lname, email FROM users;

sql

INSERT - Add Data#

Add new data:

INSERT INTO users (fname, lname, username, email) VALUES ('Anna', 'Dee', 'anna.dee', 'Anna@example.com');

sql

In JavaScript (using parameters):

const sql = 'INSERT INTO users (fname, lname, username, email) VALUES (?, ?, ?, ?)';
await pool.query(sql, ['Anna', 'Dee', 'anna.dee', 'Anna@example.com']);

javascript

UPDATE - Update Data#

Update data:

UPDATE users SET fname = 'Jane', email = 'jane@example.com' WHERE id = 3;

sql

In JavaScript:

const sql = 'UPDATE users SET fname = ?, email = ? WHERE id = ?';
await pool.query(sql, ['Jane', 'jane@example.com', 1]);

javascript

DELETE - Delete Data#

Delete data:

DELETE FROM users WHERE id = 3;

sql

In JavaScript:

await pool.query('DELETE FROM users WHERE id = ?', [3]);

javascript

JOIN - Join Tables#

LEFT JOIN - Join tables and show all left-side data:

SELECT users.id, users.fname, orders.id AS order_id
FROM users
LEFT JOIN orders ON users.id = orders.user_id;

sql

This SQL query retrieves data from the users table and the orders table using a LEFT JOIN.

It selects each user’s id and fname, along with the corresponding order_id from the orders table. The LEFT JOIN ensures that all users are included, even if they do not have any orders. If a user has no matching order, the order_id will be NULL.

The condition ON users.id = orders.user_id links each order to the correct user based on their ID.

Use JOIN with multiple tables:

SELECT o.id, u.fname, p.name, p.price
FROM orders o
JOIN users u ON o.user_id = u.id
JOIN order_product op ON o.id = op.order_id
JOIN products p ON op.product_id = p.id;

sql

Parameterized Queries (?)#

Why use ??

Secure - Prevents SQL Injection
Clean - Code is more readable
Correct - Automatically handles data types

Bad (SQL Injection risk):

const sql = `SELECT * FROM users WHERE id = ${userId}`;
// If userId = "1; DROP TABLE users;" it will be dangerous

javascript

Good (Secure):

const sql = 'SELECT * FROM users WHERE id = ?';
await pool.query(sql, [userId]);
// The ? will be replaced with a safe value

javascript

8. Create `index.js` with Express + MySQL Endpoints#

Create an index.js file in the project root and add the basic Express server code with the database connection we created:

const express = require('express');
const bodyParser = require('body-parser');
const cors = require('cors');
const pool = require('./src/db'); // Import database connection
const app = express();
const port = 5000; // Define port

// Middleware
app.use(cors());
app.use(bodyParser.json());

// Test route
app.get('/', (req, res) => {
  res.send('Hello! RESTful API is ready to use with MySQL');
});

// Add API endpoints below this line

// Start server
app.listen(port, () => {
  console.log(`Server running at http://localhost:${port}`);
});

javascript

Start and Test API Server:

node --env-file=.env index.js

bash

Open a web browser and go to http://localhost:5000 ↗, you will see the message “Hello! RESTful API is ready to use with MySQL” as shown Example result from API

Next, we will add endpoints for User, Product, and Order using SQL queries to manage data.

8.1. User Endpoints#

Add the following code to the index.js file under app.get('/')

// User Endpoints
// Read All Users
app.get('/users', async (req, res) => {
  try {
    const [rows] = await pool.query('SELECT * FROM users');
    res.json(rows);
  } catch (error) {
    res.status(500).json({ message: 'Error fetching users', error: error.message });
  }
});

// Read One User
app.get('/users/:id', async (req, res) => {
  try {
    const id = parseInt(req.params.id);
    const [rows] = await pool.query('SELECT * FROM users WHERE id = ?', [id]);
    if (rows.length === 0) {
      return res.status(404).json({ message: 'User not found' });
    }
    res.json(rows[0]);
  } catch (error) {
    res.status(500).json({ message: 'Error fetching user', error: error.message });
  }
});

// Create User
app.post('/users', async (req, res) => {
  try {
    const { fname, lname, username, email, avatar } = req.body;
    const sql = 'INSERT INTO users (fname, lname, username, email, avatar) VALUES (?, ?, ?, ?, ?)';
    const [result] = await pool.query(sql, [fname, lname, username, email, avatar || null]);

    const [newUser] = await pool.query('SELECT * FROM users WHERE id = ?', [result.insertId]);
    res.status(201).json(newUser[0]);
  } catch (error) {
    if (error.code === 'ER_DUP_ENTRY') {
      return res.status(409).json({ message: 'Username or email already exists' });
    }
    res.status(500).json({ message: 'Error creating user', error: error.message });
  }
});

// Update User
app.put('/users/:id', async (req, res) => {
  try {
    const id = parseInt(req.params.id);
    const { fname, lname, username, email, avatar } = req.body;

    // Check if user exists
    const [existing] = await pool.query('SELECT * FROM users WHERE id = ?', [id]);
    if (existing.length === 0) {
      return res.status(404).json({ message: 'User not found' });
    }

    const sql = 'UPDATE users SET fname = ?, lname = ?, username = ?, email = ?, avatar = ? WHERE id = ?';
    await pool.query(sql, [fname, lname, username, email, avatar || null, id]);

    const [updated] = await pool.query('SELECT * FROM users WHERE id = ?', [id]);
    res.status(200).json(updated[0]);
  } catch (error) {
    if (error.code === 'ER_DUP_ENTRY') {
      return res.status(409).json({ message: 'Username or email already exists' });
    }
    res.status(500).json({ message: 'Error updating user', error: error.message });
  }
});

// Delete User
app.delete('/users/:id', async (req, res) => {
  try {
    const id = parseInt(req.params.id);

    // Check if user exists
    const [existing] = await pool.query('SELECT * FROM users WHERE id = ?', [id]);
    if (existing.length === 0) {
      return res.status(404).json({ message: 'User not found' });
    }

    await pool.query('DELETE FROM users WHERE id = ?', [id]);
    res.status(200).json({ message: `User with ID ${id} deleted successfully` });
  } catch (error) {
    res.status(500).json({ message: 'Error deleting user', error: error.message });
  }
});

javascript

SQL Explanation in User Endpoints:

SELECT * FROM users
- Retrieves all columns from the users table
- Result: All users
SELECT * FROM users WHERE id = ?
- Retrieves user with id matching the specified value
- ? is a placeholder that will be replaced with a value from the array [id]
- Result: One user or empty array if not found
INSERT INTO users (…) VALUES (?, ?, ?, ?, ?)
- Adds a new user
- result.insertId is the auto-generated id
- After INSERT, SELECT again to retrieve the newly created data
UPDATE users SET … WHERE id = ?
- Updates user with id matching the specified value
- After UPDATE, SELECT to retrieve the updated data
DELETE FROM users WHERE id = ?
- Deletes user with id matching the specified value
- Data in the orders table will be deleted too (CASCADE)

Error Handling:

ER_DUP_ENTRY - Occurs when data is duplicated (username or email)
rows.length === 0 - Data not found

HTTP Method	URI	Purpose	Logic	Response
GET	/users	Get all users	Use *SELECT FROM users** to retrieve all data	List of all user objects
GET	/users/:id	Get user by ID	Use SELECT WHERE id = ? from URL parameter id, returns 404 if not found	User object or 404 (not found)
POST	/users	Create new user	req.body should have fname, lname, username, email, avatar. Use INSERT INTO users	Newly created user object or 409 (duplicate) or 500 (error)
PUT	/users/:id	Update user by ID	Update user data using ID from URL and data from Body. Handle errors (e.g., user not found or duplicate)	Updated user object or 404 (not found) or 409 (duplicate) or 500 (error)
DELETE	/users/:id	Delete user by ID	Use DELETE FROM users WHERE id = ? with specified ID	User deletion confirmation or 404 (not found) or 500 (error)

API Testing Example POST /users

Purpose Create a new user

Logic

req.body must include: fname (first name), lname (last name), username (username), email (email), and avatar (profile picture)
The system will use the INSERT INTO users command to save user data to the database

Response Object of the newly created user data API testing example POST /users

API Testing Example GET /users

Purpose Get all users

Logic

The system will use the SELECT * FROM users command to retrieve all user data from the database

Response List of objects of all user data API testing example GET /users

API Testing Example GET /users/:id

Purpose Get a single user by ID

Logic

The system will use the SELECT WHERE id = ? command using the id value from the URL parameter
If user is not found, the system will return status 404 (Not Found)

Response Object of a single user data

API testing example GET /users/:id

API testing example GET /users/:id when user not found

API Testing Example PUT /users/:id

Purpose Update user data by ID

Logic

The system will parse the id value from the URL
Use the UPDATE users SET … WHERE id = ? command with the new data to be updated
Error handling is included (e.g., user not found case)

Response Object of updated user data

API testing example PUT /users/:id

API Testing Example DELETE /users/:id

Purpose Delete user by ID

Logic

The system will use the DELETE FROM users WHERE id = ? command with the specified ID value

Response User deletion confirmation

API testing example DELETE /users/:id

8.2. Product Endpoints#

Add the following code to the index.js file

// Product Endpoints
// Read All Products
app.get('/products', async (req, res) => {
  try {
    const [rows] = await pool.query('SELECT * FROM products');
    res.json(rows);
  } catch (error) {
    res.status(500).json({ message: 'Error fetching products', error: error.message });
  }
});

// Read One Product
app.get('/products/:id', async (req, res) => {
  try {
    const id = parseInt(req.params.id);
    const [rows] = await pool.query('SELECT * FROM products WHERE id = ?', [id]);
    if (rows.length === 0) {
      return res.status(404).json({ message: 'Product not found' });
    }
    res.json(rows[0]);
  } catch (error) {
    res.status(500).json({ message: 'Error fetching product', error: error.message });
  }
});

// Create Product
app.post('/products', async (req, res) => {
  try {
    const { name, price } = req.body;
    const sql = 'INSERT INTO products (name, price) VALUES (?, ?)';
    const [result] = await pool.query(sql, [name, price]);

    const [newProduct] = await pool.query('SELECT * FROM products WHERE id = ?', [result.insertId]);
    res.status(201).json(newProduct[0]);
  } catch (error) {
    res.status(500).json({ message: 'Error creating product', error: error.message });
  }
});

// Update Product
app.put('/products/:id', async (req, res) => {
  try {
    const id = parseInt(req.params.id);
    const { name, price } = req.body;

    // Check if product exists
    const [existing] = await pool.query('SELECT * FROM products WHERE id = ?', [id]);
    if (existing.length === 0) {
      return res.status(404).json({ message: 'Product not found' });
    }

    const sql = 'UPDATE products SET name = ?, price = ? WHERE id = ?';
    await pool.query(sql, [name, price, id]);

    const [updated] = await pool.query('SELECT * FROM products WHERE id = ?', [id]);
    res.status(200).json(updated[0]);
  } catch (error) {
    res.status(500).json({ message: 'Error updating product', error: error.message });
  }
});

// Delete Product
app.delete('/products/:id', async (req, res) => {
  try {
    const id = parseInt(req.params.id);

    // Check if product exists
    const [existing] = await pool.query('SELECT * FROM products WHERE id = ?', [id]);
    if (existing.length === 0) {
      return res.status(404).json({ message: 'Product not found' });
    }

    await pool.query('DELETE FROM products WHERE id = ?', [id]);
    res.status(200).json({ message: `Product with ID ${id} deleted successfully` });
  } catch (error) {
    res.status(500).json({ message: 'Error deleting product', error: error.message });
  }
});

javascript

HTTP Method	URI	Purpose	Logic	Response
GET	/products	Get all products	Use *SELECT FROM products** to retrieve all data	List of all product objects
GET	/products/:id	Get product by ID	Use SELECT WHERE id = ? from URL parameter id, returns 404 if not found	Product object or 404 (not found)
POST	/products	Create new product	req.body should have product data. Use INSERT INTO products	Newly created product object or 500 (error)
PUT	/products/:id	Update product by ID	Update product data using ID from URL and data from Body. Handle errors (e.g., product not found)	Updated product object or 404 (not found) or 500 (error)
DELETE	/products/:id	Delete product by ID	Use DELETE FROM products WHERE id = ? with specified ID	Product deletion confirmation or 404 (not found) or 500 (error)

API Testing Example POST /products

Purpose Create a new product

Logic

req.body should include product data
The system will use the INSERT INTO products command to save product data to the database

Response Object of the newly created product data

API testing example POST /products

API Testing Example GET /products

Purpose Get all products

Logic

The system will use the SELECT * FROM products command to retrieve all product data from the database

Response List of objects of all product data

API testing example GET /products

API Testing Example GET /products/:id

Purpose Get a single product by ID

Logic

The system will use the SELECT WHERE id = ? command using the id value from the URL parameter
If product is not found, the system will return status 404 (Not Found)

Response Object of a single product data

API testing example GET /products/:id

API Testing Example PUT /products/:id

Purpose Update product data by ID

Logic

The system will parse the id value from the URL
Use the UPDATE products SET … WHERE id = ? command with the new data to be updated
Error handling is included (e.g., product not found case)

Response Object of updated product data

API testing example PUT /products/:id

API Testing Example DELETE /products/:id

Purpose Delete product by ID

Logic

The system will use the DELETE FROM products WHERE id = ? command with the specified ID value

Response Product deletion confirmation

API testing example DELETE /products/:id

8.3. Order Endpoints#

Add the following code to the index.js file

// Order Endpoints
// Read All Orders
app.get('/orders', async (req, res) => {
  try {
    const [orders] = await pool.query(`
      SELECT
        o.id,
        o.user_id,
        o.created_at,
        u.id as user_id,
        u.fname,
        u.lname,
        u.username,
        u.email,
        u.avatar
      FROM orders o
      JOIN users u ON o.user_id = u.id
    `);

    // Get products for each order
    for (const order of orders) {
      const [products] = await pool.query(`
        SELECT p.*
        FROM products p
        JOIN order_product op ON p.id = op.product_id
        WHERE op.order_id = ?
      `, [order.id]);
      order.products = products;
      order.user = {
        id: order.user_id,
        fname: order.fname,
        lname: order.lname,
        username: order.username,
        email: order.email,
        avatar: order.avatar
      };
      delete order.fname;
      delete order.lname;
      delete order.username;
      delete order.email;
      delete order.avatar;
    }

    res.json(orders);
  } catch (error) {
    res.status(500).json({ message: 'Error fetching orders', error: error.message });
  }
});

// Read One Order
app.get('/orders/:id', async (req, res) => {
  try {
    const id = parseInt(req.params.id);
    const [orders] = await pool.query(`
      SELECT
        o.id,
        o.user_id,
        o.created_at,
        u.fname,
        u.lname,
        u.username,
        u.email,
        u.avatar
      FROM orders o
      JOIN users u ON o.user_id = u.id
      WHERE o.id = ?
    `, [id]);

    if (orders.length === 0) {
      return res.status(404).json({ message: 'Order not found' });
    }

    const order = orders[0];

    // Get products for the order
    const [products] = await pool.query(`
      SELECT p.*
      FROM products p
      JOIN order_product op ON p.id = op.product_id
      WHERE op.order_id = ?
    `, [id]);

    order.products = products;
    order.user = {
      id: order.user_id,
      fname: order.fname,
      lname: order.lname,
      username: order.username,
      email: order.email,
      avatar: order.avatar
    };
    delete order.fname;
    delete order.lname;
    delete order.username;
    delete order.email;
    delete order.avatar;

    res.json(order);
  } catch (error) {
    res.status(500).json({ message: 'Error fetching order', error: error.message });
  }
});

// Create Order
app.post('/orders', async (req, res) => {
  const connection = await pool.getConnection();
  try {
    await connection.beginTransaction();
    const { userId, productIds } = req.body;

    // Check if user exists
    const [users] = await connection.query('SELECT * FROM users WHERE id = ?', [userId]);
    if (users.length === 0) {
      await connection.rollback();
      return res.status(400).json({ message: 'Invalid user ID' });
    }

    // Create order
    const [orderResult] = await connection.query('INSERT INTO orders (user_id) VALUES (?)', [userId]);
    const orderId = orderResult.insertId;

    // Add products to order
    for (const productId of productIds) {
      await connection.query('INSERT INTO order_product (order_id, product_id) VALUES (?, ?)', [orderId, productId]);
    }

    await connection.commit();

    // Get complete order data
    const [orders] = await pool.query(`
      SELECT
        o.id,
        o.user_id,
        o.created_at,
        u.fname,
        u.lname,
        u.username,
        u.email,
        u.avatar
      FROM orders o
      JOIN users u ON o.user_id = u.id
      WHERE o.id = ?
    `, [orderId]);

    const [products] = await pool.query(`
      SELECT p.*
      FROM products p
      JOIN order_product op ON p.id = op.product_id
      WHERE op.order_id = ?
    `, [orderId]);

    const order = orders[0];
    order.products = products;
    order.user = {
      id: order.user_id,
      fname: order.fname,
      lname: order.lname,
      username: order.username,
      email: order.email,
      avatar: order.avatar
    };
    delete order.fname;
    delete order.lname;
    delete order.username;
    delete order.email;
    delete order.avatar;

    res.status(201).json(order);
  } catch (error) {
    await connection.rollback();
    if (error.code === 'ER_NO_REFERENCED_ROW_2') {
      return res.status(400).json({ message: 'Invalid user ID or product ID' });
    }
    res.status(500).json({ message: 'Error creating order', error: error.message });
  } finally {
    connection.release();
  }
});

// Update Order
app.put('/orders/:id', async (req, res) => {
  const connection = await pool.getConnection();
  try {
    await connection.beginTransaction();
    const id = parseInt(req.params.id);
    const { userId, productIds } = req.body;

    // Check if order exists
    const [existing] = await connection.query('SELECT * FROM orders WHERE id = ?', [id]);
    if (existing.length === 0) {
      await connection.rollback();
      return res.status(404).json({ message: 'Order not found' });
    }

    // Update order user
    await connection.query('UPDATE orders SET user_id = ? WHERE id = ?', [userId, id]);

    // Delete old products and add new ones
    await connection.query('DELETE FROM order_product WHERE order_id = ?', [id]);
    for (const productId of productIds) {
      await connection.query('INSERT INTO order_product (order_id, product_id) VALUES (?, ?)', [id, productId]);
    }

    await connection.commit();

    // Get complete order data
    const [orders] = await pool.query(`
      SELECT
        o.id,
        o.user_id,
        o.created_at,
        u.fname,
        u.lname,
        u.username,
        u.email,
        u.avatar
      FROM orders o
      JOIN users u ON o.user_id = u.id
      WHERE o.id = ?
    `, [id]);

    const [products] = await pool.query(`
      SELECT p.*
      FROM products p
      JOIN order_product op ON p.id = op.product_id
      WHERE op.order_id = ?
    `, [id]);

    const order = orders[0];
    order.products = products;
    order.user = {
      id: order.user_id,
      fname: order.fname,
      lname: order.lname,
      username: order.username,
      email: order.email,
      avatar: order.avatar
    };
    delete order.fname;
    delete order.lname;
    delete order.username;
    delete order.email;
    delete order.avatar;

    res.status(200).json(order);
  } catch (error) {
    await connection.rollback();
    if (error.code === 'ER_NO_REFERENCED_ROW_2') {
      return res.status(400).json({ message: 'Invalid user ID or product ID' });
    }
    res.status(500).json({ message: 'Error updating order', error: error.message });
  } finally {
    connection.release();
  }
});

// Delete Order
app.delete('/orders/:id', async (req, res) => {
  try {
    const id = parseInt(req.params.id);

    // Check if order exists
    const [existing] = await pool.query('SELECT * FROM orders WHERE id = ?', [id]);
    if (existing.length === 0) {
      return res.status(404).json({ message: 'Order not found' });
    }

    // Delete related order_product records (will be auto-deleted by CASCADE)
    await pool.query('DELETE FROM orders WHERE id = ?', [id]);
    res.status(200).json({ message: `Order with ID ${id} deleted successfully` });
  } catch (error) {
    res.status(500).json({ message: 'Error deleting order', error: error.message });
  }
});

javascript

SQL JOIN Explanation in Order Endpoints:

1. JOIN to retrieve order data with user:

SELECT
  o.id, o.user_id, o.created_at,
  u.fname, u.lname, u.username, u.email, u.avatar
FROM orders o
JOIN users u ON o.user_id = u.id

sql

o and u are aliases (abbreviations) of table names
JOIN users u ON o.user_id = u.id joins orders table with users
Result: Orders with user data

2. JOIN to retrieve products in an order:

SELECT p.*
FROM products p
JOIN order_product op ON p.id = op.product_id
WHERE op.order_id = ?

sql

Joins products table with order_product
Filters only products in the specified order

3. Transaction for CREATE/UPDATE:

const connection = await pool.getConnection();
try {
  await connection.beginTransaction();
  // Multiple SQL commands
  await connection.commit();
} catch (error) {
  await connection.rollback();
}

javascript

Transaction is used when multiple commands must all succeed
commit - Confirm changes
rollback - Cancel changes if an error occurs

4. INSERT with relationships:

INSERT INTO orders (user_id) VALUES (?);           -- Create order
INSERT INTO order_product (order_id, product_id)   -- Link products
VALUES (?, ?);

sql

5. DELETE with CASCADE:

DELETE FROM orders WHERE id = ?
-- Data in order_product will be auto-deleted (CASCADE)

sql

HTTP Method	URI	Purpose	Logic	Response
GET	/orders	Get all orders	Use JOIN to retrieve order data with users and products	List of all order objects with user and product data
GET	/orders/:id	Get order by ID	Use JOIN WHERE id = ? with product data, returns 404 if not found	Order object with user and product data or 404 (not found)
POST	/orders	Create new order	req.body must have userId and productIds. Use Transaction and INSERT with creating product relationships	Newly created order object with user and product data or 400 (invalid data) or 500 (error)
PUT	/orders/:id	Update order by ID	Update order data, delete old products and add new ones. Handle errors	Updated order object with user and product data or 404 (not found) or 400 (invalid data) or 500 (error)
DELETE	/orders/:id	Delete order by ID	Delete order (order_product data will be deleted by CASCADE)	Order deletion confirmation or 404 (not found) or 500 (error)

API Testing Example POST /orders

Purpose Create a new order

Logic

req.body must include: userId (user ID) and productIds (list of product IDs)
The system will use the INSERT INTO orders and INSERT INTO order_product commands with Transaction to create an order and link it with selected products
Data will be returned with user and product details

Response Object of the newly created order data with user and product details

API testing example POST /orders

API Testing Example GET /orders

Purpose Get all orders

Logic

The system will use the JOIN command to retrieve all order data with users and products

Response List of objects of all order data with users and products

API testing example GET /orders

API Testing Example GET /orders/:id

Purpose Get a single order by ID

Logic

The system will use the JOIN WHERE id = ? command using the id value from the URL parameter
Use JOIN to retrieve related user and product data
If order is not found, the system will return status 404 (Not Found)

Response Object of a single order data with user and product details

API testing example GET /orders/:id

API Testing Example PUT /orders/:id

Purpose Update order data by ID

Logic

The system will parse the id value from the URL
Use the UPDATE orders and DELETE/INSERT order_product commands with new data in Transaction
Delete all relationships with old products and create new relationships with selected products
Error handling is included (e.g., order not found case)

Response Object of updated order data with user and product details

API testing example PUT /orders/:id

API Testing Example DELETE /orders/:id

Purpose Delete order by ID

Logic

The system will use the DELETE FROM orders WHERE id = ? command
Data in the order_product table will be auto-deleted by CASCADE

Response Order deletion confirmation

API testing example DELETE /orders/:id |

8.4. Nested Endpoints#

Add the following code to the index.js file to create endpoints for nested resources:

// Relationship Endpoints
// Get Orders by User ID
app.get('/users/:id/orders', async (req, res) => {
  const id = parseInt(req.params.id);
  try {
    // Check if user exists
    const [users] = await pool.query('SELECT * FROM users WHERE id = ?', [id]);
    if (users.length === 0) {
      return res.status(404).json({ message: 'User not found' });
    }

    const [orders] = await pool.query(`
      SELECT
        o.id,
        o.user_id,
        o.created_at,
        u.fname,
        u.lname,
        u.username,
        u.email,
        u.avatar
      FROM orders o
      JOIN users u ON o.user_id = u.id
      WHERE o.user_id = ?
    `, [id]);

    // Get products for each order
    for (const order of orders) {
      const [products] = await pool.query(`
        SELECT p.*
        FROM products p
        JOIN order_product op ON p.id = op.product_id
        WHERE op.order_id = ?
      `, [order.id]);
      order.products = products;
      order.user = {
        id: order.user_id,
        fname: order.fname,
        lname: order.lname,
        username: order.username,
        email: order.email,
        avatar: order.avatar
      };
      delete order.fname;
      delete order.lname;
      delete order.username;
      delete order.email;
      delete order.avatar;
    }

    res.json(orders);
  } catch (error) {
    res.status(500).json({ message: 'Error fetching user orders', error: error.message });
  }
});

// Get Products by Order ID
app.get('/orders/:id/products', async (req, res) => {
  const id = parseInt(req.params.id);
  try {
    // Check if order exists
    const [orders] = await pool.query('SELECT * FROM orders WHERE id = ?', [id]);
    if (orders.length === 0) {
      return res.status(404).json({ message: 'Order not found' });
    }

    const [products] = await pool.query(`
      SELECT p.*
      FROM products p
      JOIN order_product op ON p.id = op.product_id
      WHERE op.order_id = ?
    `, [id]);

    res.json(products);
  } catch (error) {
    res.status(500).json({ message: 'Error fetching order products', error: error.message });
  }
});

javascript

HTTP Method	URI	Purpose	Logic	Response
`GET`	`/users/:id/orders`	Get all orders of a user	Check if user exists, then use `JOIN WHERE user_id = ?`	List of order objects for that user with product data or 404 (user not found) or 500 (error)
`GET`	`/orders/:id/products`	Get all products in an order	Use `JOIN` to find order with products, then return only product data	List of product objects in that order or 404 (order not found) or 500 (error)

API Testing Example GET /users/:id/orders

Purpose Get all orders of a single user

Logic

The system will check if the user with the specified id exists in the database
If user is found, the system will use the JOIN WHERE user_id = ? command filtered by user_id
Use JOIN to retrieve related product and user data
If user is not found, the system will return status 404 (User not found)

Response List of objects of all orders for that user with product data

API testing example GET /users/:id/orders

API Testing Example GET /orders/:id/products

Purpose Get all products in a single order

Logic

The system will use the JOIN command using the id value of the order from the URL parameter
Use JOIN to retrieve product data related to the order
If order is not found, the system will return status 404 (Order not found)

Response List of objects of all products in that order

API testing example GET /orders/:id/products

Additional Notes

These Relationship Endpoints make accessing related data more convenient:

/users/:id/orders - Suitable for displaying order history of each customer
/orders/:id/products - Suitable for displaying product list in a specific order

Both of these endpoints help reduce complexity in data retrieval from the frontend and make the API more flexible to use.

Understanding API structure and writing SQL queries directly will help you better understand Web Application development principles and database management.

1. Objectives#

2. Install Programs and Setup Database#

3. Setup Project and Install MySQL Driver#

4. Create Database Tables#

Table Structure Summary#

SQL Commands Explanation for Creating Tables#

5. Add Sample Data (Seed Data)#

SQL Commands Explanation for Adding Data#

6. Create Database Connection File#

Connection Pool Explanation#

7. Basic SQL Commands Used in RESTful API#

SELECT - Retrieve Data#

INSERT - Add Data#

UPDATE - Update Data#

DELETE - Delete Data#

JOIN - Join Tables#

Parameterized Queries (?)#

8. Create index.js with Express + MySQL Endpoints#

8.1. User Endpoints#

8.2. Product Endpoints#

8.3. Order Endpoints#

8.4. Nested Endpoints#

Login to comment

Comments 0

Delete Comment

8. Create `index.js` with Express + MySQL Endpoints#
